MIDO Gas protecttorelay MDC201F/U
MDC201F
⊙ Nominal
⊙ Nominal
. Nominal voltage : AC 200~240V 50/60㎐ 1phase
. Ambient temperature : -20℃ ～ 60℃
. Ambient air density : 35% ～ 85% (however, while not frozen.)
. Power capacity : AC250V 5A
. Power consumption : < MAX 5W , AC 20mA
⊙ Fire detection
. Ignition detection current : >DC 2㎂
. Misfiring current : <DC 0.7㎂
MDC201U
⊙ Nominal
. Nominal voltage : AC 200~240V 50/60㎐ 1phase
. Ambient temperature : -20℃ ～ 60℃
. Ambient air density : 35% ～ 85% (however, while not frozen)
. Power capacity : AC250V 5A
. Power consumption : < MAX 5W , AC 20mA
⊙ Fire detection
. Ignition detection current : >1.5㎃ (UV 7027A or 7035)
. Misfiring current : <1㎃ (UV 7027A or 7035)
